General |
|
| PHYSICAL DIMENSIONS | 26.4" x 25.3" (670 x 642 mm) |
|---|---|
| WEIGHT |
50.3 lbs (22.8 kg) |
| HEIGHT | 18.1" (460 mm) |
Connectivity |
|
| WIRELESS COMMUNICATION |
ANT+ connectivity, BLUETOOTH wireless technology |
|---|---|
| CONTROL BY |
Smartphone, tablet, ANT+ bike computers, stand alone, computer connection via ANT+ antenna |
| READ OUT ON |
Smartphone, tablet, bike computer, computer with ANT+ antenna |
Indoor Training Features |
|
| MAGNETS | 8 permanent ferrite magnets and 8 electromagnets |
|---|---|
| ELECTRICAL REQUIREMENT | 110-240 V |
| SUITABLE CASSETTES |
Shimano and SRAM: 8-11 speed. Campagnolo, SRAM XD and XD-R body (sold separately). Not suitable for specialized SCS system. |
| SUITABLE AXLES |
Width of rear fork: Race 130 mm, MTB 135 mm. Adapters for other widths available. |
| MAX POWER | 1500 watt |
| MAX INCLINE | 10% |
| MAX TORQUE | 22.1 Nm |
| MAX BRAKE FORCE | 65N |
| FLYWHEEL | 15.4 lbs (7 kg) |
| MASS INERTIA | 50.3 lbs (22.8 kg) |
| CALIBRATION | Spin down |
| OUTPUT | Speed, cadence, power |
| ACCURACY | <3% |
| Magnets | 8 permanent ferrite magnets and 8 electromagnets |
| Electrical requirement | 110-240 V |
| Connection Indicator (ANT+/Bluetooth) | 2 LEDs |
| Suitable cassettes | Shimano and SRAM: 8-11 speed. Campagnolo, SRAM XD and XD-R body (sold separately). Not suitable for specialised SCS system |
| Suitable axles | Width of rear fork: Race 130 mm, MTB 135 mm. Adapters for other widths available |
| Max power | 1500 watt |
| Max incline | 10% |
| Max torque | 22.1 Nm |
| Max brake force | 65 N |
| Flywheel | 7 kg |
| Mass inertia | 22.8 kg |
| Calibration | Spin down |
| Footprint | 670 x 642 mm |
| Height | 460 mm |
| Weight | 22.8 kg |
| Wireless communication | ANT+ connectivity, BLUETOOTH wireless technology |
| Control by | Smartphone, tablet, ANT+ bike computers, stand alone, computer connection via ANT+ antenna |
| Output | Speed, cadence, power |
| Read out on | Smartphone, tablet, bike computer, computer with ANT+ antenna |
| Accuracy | < 3% |
