2026 Trek Marlin 4 Gen 3 - Matte Dark Web
Regular price
R 13,000.00 ZAR
Shipping calculated at checkout.
Marlin 4 is a trail-worthy daily rider that's perfectly suited for everyday adventures, on and off the trail. It features a trail-savvy frame with a suspension fork, 8-speed Shimano ESSA shifting and mounts for a rack and kickstand that make it an ideal choice for trail riders or anyone looking for a comfortable, stable commuter with the ruggedness of a real mountain bike.
OVERVIEW
SPECS
*Please note – spec applies to all sizes unless listed separately
Frameset
| *Frame |
Size: XS
Alpha Silver Aluminium, curved top tube, internal derailleur and dropper post routing, rack and kickstand mount, 135x5 mm ThruSkew
|
|---|---|
|
Size: ML , M , L , S , XL , XXL
Alpha Silver Aluminium, internal derailleur and dropper post routing, rack and kickstand mount, 135x5 mm ThruSkew
|
|
| *Fork |
Size: XS
SR Suntour XCE 28, coil spring, preload, 42 mm offset for 27.5" wheel, 100 mm QR, 80 mm travel
|
|
Size: S
SR Suntour XCE 28, coil spring, preload, 42 mm offset for 27.5" wheel, 100 mm QR, 100 mm travel
|
|
|
Size: ML , M , L , XL , XXL
SR Suntour XCE 28, coil spring, preload, 46 mm offset for 29" wheel, 100 mm QR, 100 mm travel
|
Wheels
| *Front Hub |
Size: ML , M , XS , L , S , XL , XXL
Formula DC-20, alloy, 6-bolt, 5x100 mm QR
|
|---|---|
| *Rear Hub |
Size: ML , M , XS , L , S , XL , XXL
Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR
|
| *Rear Skewer | Size: ML , M , XS , L , S , XL , XXL173x5 mm QR |
| *Rim |
Size: ML , M , XS , L , S , XL , XXL
Bontrager Connection, double-wall, 32-hole, 20 mm width, Schrader valve
|
| *Tire |
Size: XS , S
Bontrager Montrose comp, wire bead, 30 tpi, 27.5x2.40"
|
|
Size: ML , M , L , XL , XXL
Bontrager Montrose comp, wire bead, 30 tpi, 29x2.40"
|
Drivetrain
| *Shifter |
Size: ML , M , XS , L , S , XL , XXL
Shimano M315, 8-speed
|
|---|---|
| *Rear Derailleur |
Size: ML , M , XS , L , S , XL , XXL
Shimano ESSA U2000
|
| *Crank |
Size: XS
ProWheel alloy, 32T narrow-wide steel ring, 160 mm length
|
|
Size: ML , M , S
ProWheel alloy, 32T narrow-wide steel ring, 170 mm length
|
|
|
Size: L , XL , XXL
ProWheel alloy, 32T narrow-wide steel ring, 175 mm length
|
|
| *Cassette |
Size: ML , M , XS , L , S , XL , XXL
Shimano HG300, 11-45, 8-speed
|
| *Chain |
Size: ML , M , XS , L , S , XL , XXL
KMC Z8.3, 8-speed
|
| *Pedal |
Size: ML , M , XS , L , S , XL , XXL
Nylon platform
|
Components
| *Saddle |
Size: ML , M , XS , L , S , XL , XXL
Bontrager Verse Short, stainless steel rails
|
|---|---|
| *Seatpost |
Size: M , XS , S
Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length
|
|
Size: ML , L , XL , XXL
Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length
|
|
| *Handlebar |
Size: XS
Bontrager alloy, 31.8 mm, 5 mm rise, 690 mm width
|
|
Size: S
Bontrager alloy, 31.8 mm, 15 mm rise, 720 mm width
|
|
|
Size: ML , M , L , XL , XXL
Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width
|
|
| *Grips |
Size: ML , M , XS , L , S , XL , XXL
Trek Line Comp, nylon lock-on
|
| *Stem |
Size: XS , S
Bontrager Comp, 31.8 mm, 7-degree, 35 mm length
|
| Size: ML , M , LBontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length | |
| Size: XLBontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 60 mm length | |
| Size: XXLBontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 70 mm length | |
| *Headset |
Size: ML , M , XS , L , S , XL , XXL
Semi-integrated, 1-1/8''
|
| *Brake |
Size: XS , S
Tektro HD-M276 hydraulic disc
|
|
Size: ML , M , XS , L , S , XL , XXL
Power BH-M286TF hydraulic disc, 160 mm rotor
|
|
|
Size: ML , M , L , XL , XXL
Tektro HD-M275 hydraulic disc
|
|
|
Size: ML , M , L , XL , XXL
Power BH-M286TF hydraulic disc, 180 mm rotor
|
|
| *Brake Rotor |
Size: ML , M , XS , L , S , XL , XXL
Tektro, 6-bolt, 160mm
|
|
Size: ML , M , L , XL , XXL
Tektro, 6-bolt, 180mm
|
Weight
| Weight | M - 14.90 kg / 32.85 lbs |
|---|---|
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
